Product detailed description
The 22209 HLKM spherical roller bearing offers robust support for heavy radial and axial loads in both directions. Its self-aligning design compensates for shaft misalignments, making it ideal for applications with shaft deflections or housing distortions. This bearing is commonly used in industrial machinery, conveyors, and other equipment requiring high load capacity and alignment flexibility.
Technical Specifications:
-
Type: Spherical roller bearing
-
Design: Self-aligning, double-row
-
Inner Diameter (d): 45 mm
-
Outer Diameter (D): 85 mm
-
Width (B): 23 mm
-
Dynamic Load Rating (C): 102.0 kN
-
Static Load Rating (C₀): 98.0 kN
-
Limiting Speed: 10,000 RPM
-
Temperature Range: -30°C to +150°C (short-term up to +200°C)
-
Lubrication: Equipped with a groove and three lubrication holes for efficient relubrication
-
Material: Bearing steel
-
Weight: Approximately 580 g
This bearing's high load capacity and self-aligning capabilities make it suitable for demanding industrial applications. Ensure proper installation and lubrication to maintain optimal performance and longevity.
