Bearing 22317 KJW33 ZKL
Worldwide delivery
Best prices
Verified quality
Related products
Product detailed description
The ZKL 22317 KJW33 spherical roller bearing is engineered to handle heavy radial and axial loads in both directions, making it ideal for demanding industrial applications.
Technical Specifications:
-
Dimensions:
- Inner Diameter (d): 85 mm
- Outer Diameter (D): 180 mm
- Width (B): 60 mm
- Radius of Inner Ring (rₛ): 3 mm
- Radius of Outer Ring (rₛ): 3 mm
- Distance from Center to Center of Roller (a): 4.5 mm
- Distance from Center to Center of Roller (b): 8.3 mm
- Mass: 7.08 kg
-
Load Ratings:
- Basic Dynamic Load Rating (Cᵣ): 530 kN
- Basic Static Load Rating (C₀ᵣ): 603 kN
- Fatigue Load Limit (Cᵤ): 66.9 kN
-
Speed Ratings:
- Reference Speed with Grease Lubrication (nG): 2000 min⁻¹
- Reference Speed with Oil Lubrication (nₒ): 2600 min⁻¹
-
Calculation Factors:
- e: 0.32
- Y₀: 2
- Y₁: 2.1
- Y₂: 3.1
-
Temperature Range:
- Maximum Operating Temperature: 200°C
-
Lubrication:
- Suitable for both grease and oil lubrication systems
-
Design Features:
- Reinforced construction for enhanced durability
- Designed to accommodate misalignment and shaft deflections
This bearing is commonly used in applications such as:
- Mining equipment
- Construction machinery
- Heavy-duty industrial machinery
For optimal performance, ensure proper installation and maintenance practices are followed.
Be the first who will post an article to this item!
Add a rating
ZKL Bearings - Quality and Performance for Every Application
ZKL bearings are known for their high quality, reliability, and long service life. This renowned Czech manufacturer specializes in producing a wide range of bearings for various industrial sectors, including automotive, machinery, energy, and more. ZKL bearings are known for their excellent performance even under demanding conditions and are favored for their durability and long life.
Why Choose ZKL Bearings?
- Excellent Price/Performance Ratio: ZKL bearings offer great performance at a highly competitive price, making them an ideal choice for a wide range of applications.
- High Reliability: ZKL bearings are designed for long life and minimal maintenance, reducing repair and replacement costs over time.
- Variety of Products: ZKL offers a wide range of bearings, including ball, roller, and other types, which meet the specific requirements of various industrial applications.
Technical Specifications
ZKL bearings are designed to provide optimal performance in different conditions. They offer a wide selection of sizes and bearing types, including versions for high loads, high speeds, or extreme temperatures. Choose based on specifications such as diameter, width, material, and other technical parameters.
Contact Us
If you're looking for high-quality ZKL bearings for your applications, reach out to us. Our company provides not only top-notch products but also expert advice to help you select the right bearings for your specific needs. We are ready to ensure fast delivery and answer any questions you may have.
Interested in ZKL bearings? Order from us today!
