Product detailed description
The 3214 SRO is a double-row angular contact ball bearing renowned for its ability to handle both radial and axial loads effectively. This bearing type is particularly suitable for applications requiring high load capacity and precision.
Technical Specifications:
-
Bore Diameter (d): 70.000 mm
-
Outer Diameter (D): 125.000 mm
-
Width (B): 39.700 mm
-
Contact Angle: 32°
-
Cage Type: Pressed steel
-
Cage Material: Steel
-
Ball Material: Steel
-
Precision Class: Class 0
-
Radial Internal Clearance: CN (Normal)
-
Static Load Rating: 119.00 kN
-
Dynamic Load Rating: 93.00 kN
-
Operating Temperature Range: -40 to 120°C
-
Enclosure: Open (no seals)
This bearing is ideal for use in machinery and equipment where space constraints and the need for high load capacity are critical. Its open design allows for easy lubrication and maintenance, making it a versatile choice for various industrial applications.
